Aluminum Foil Surface Painting Embossing and Scuttling Printing machine with Air cooling system and winding unit

Large Image : Aluminum Foil Surface Painting Embossing and Scuttling Printing machine with Air cooling system and winding unit

Product Details:

Place of Origin:	China
Brand Name:	Upper Bond
Certification:	CO

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	Negotiation
Packaging Details:	Wooden case
Delivery Time:	40 Works Days
Payment Terms:	L/C, T/T
Supply Ability:	50sets/year

Contact Now

Detailed Product Description

Name:	Multi-Function Aluminum Foil Composite Machine	Effective Working Width:	570mm
Suitable Material Thickness:	Aluminum Foil:0.006-0.014mm Liner: 21-80g/m2	Work Wire-speed:	5-80m / Min
Maximum Unwinding Diameter:	Aluminum Foil:Φ400mm Liner: Φ1000mm	Drive Motor Power:	5.5KW
Total Power:	38KW	Dimensions:	9640×1600×2720mm
Total Weight:	3.5T
Highlight:	Air Cooling Surface Painting Machine , Aluminum Foil Surface Painting Machine , Scuttling Printing Surface Painting Machine

Aluminum Foil Surface Painting Embossing and Scuttling Printing machine with Air cooling system and winding unit

Introduction

BFY-650W multi-foil composite machine in China Occupies 80% of the tobacco packaging industry. The device has a monochrome printing paper surface. Foil surface coloring. Coating compound. Drying.and Air cooling system and rolling units

Features

1, back printing (printing), composite, printing oiling, embossing, winding continuous completion, can also be used separately;

2, mechanical transmission adopts servo system shaftless transmission, reliable and stable operation;

3, each pressing point action pneumatic execution;

4, the machine can do monochrome back printing (or front printing) on the lining paper, which can improve the anti-counterfeiting ability and competitiveness of the product;

5. Special hot pressing mechanism after composite to improve the surface quality of the product;

6, hot air circulation heating oven, improve the heat utilization rate, increase the equipment running speed;

7, the backward winding mechanism can make the winding diameter reach φ1000mm.

Technical Parameters:

Effective working width	570mm
Suitable material thickness	aluminum foil:0.006-0.014mm liner: 21-80g/m2
Work wire-speed	5-80m / min
Maximum unwinding diameter	Φ400mm foil backing Φ1000mm
Maximum rewinding diameter	Φ1000mm
Rolling torque motor	4Kg.m
The total heating power	31.8KW
Drive motor power	5.5KW
Total power	38KW
Dimensions	(L × W × H) 9640 × 1600 × 27200mm
Total weight	3.5T
