84mm Length Weight Diameter Hardness Cigarette Filter Rods Testing device

 84mm Length Weight Diameter Hardness Cigarette Filter Rods Testing device


Weight Tester:

1. Suitable for various specifications of cigarettes, filter rod products;
2. Industrial tablet computer control core, suitable for various environments such as industrial sites;
3. Adopt imported high precision electronic balance, high precision, high resolution
4. High-speed automatic measurement, intelligent real-time self-test;
5. Chinese graphical interface, touch screen operation, easy to use, quick to master;
6. Perfect data processing function, data can be exchanged through various interfaces to achieve data sharing.

Main technical index:




Circumference Tester:
1. Suitable for all kinds of cigarette and filter rod products;
2. Embedded technology, industrial tablet PC control core, suitable for various environments such as industrial site;
3. Imported laser micrometer, non-contact measurement, high precision, high resolution;
4. Lightweight cylinder measuring and holding system with independent intellectual property rights,


Main technical indicators
Sample length range: 55 ~ 150mm
sample circumference range: 15.5 ~ 28.5mm
Measuring range: 15.5 ~ 28.5mm
circumferential measuring point to end face distance range: 47 ~ 119mm
Resolution: 0.005mm (IG028 used as sensor)
Measurement accuracy: 0.001mm (using LS7000 as a sensor)
±0.005mm (IG028 used as sensor)
±0.002mm (using LS7000 as sensor)


PD Tester

Main technical indicators

Sample length range: 55 ~ 150mm sample circumference range: 15.5 ~ 28.5mm
Measuring range: suction resistance: 0-10000Pa (can be customized, the highest 0-15000Pa) Ventilation rate: 0-100%
Resolution: suction resistance: 1Pa ventilation rate: 0.1%
Accuracy: suction resistance: ±0.5%FS ventilation rate: ±1.0%FS
Fixed airflow velocity: 17.5±0.1ml/s


Length Tester

Main technical indicators
Sample length range: 55 ~ 150mm
sample circumference range: 15.5 ~ 28.5mm
Measuring range: 15.5 ~ 28.5mm circumferential measuring point to end face distance range: 47 ~ 119mm
Resolution: 0.005mm (IG028 used as sensor)
Measurement accuracy: 0.001mm (using LS7000 as a sensor)
±0.005mm (IG028 used as sensor)
±0.002mm (using LS7000 as sensor)


hardness Tester

1. Suitable for various specifications of cigarettes, filter rod products;
2. Industrial tablet computer control core, suitable for various environments such as industrial sites;
3. Imported laser sensor, high precision, high resolution;
4. The use of weights direct vertical pressure, air bearing zero friction, laser non-contact measurement and other advanced technology,
Precise control of pressure load, precise mechanism, stable and reliable work;
5. Sample automatic alignment, measurement position can be stepless, wide range setting;


Main technical indicators

Sample length range: 55 ~ 150mm Sample circumference range: 15.5 ~ 28.5mm
Measuring range: 0 ~ 100% Measuring accuracy: ±0.5%
Pressure load: 2.94N±0.01N Compression time: 15s±1s
Sag detection range: 0 ~ 10mm Sag detection accuracy: ±0.005mm


Environmental requirement

Ambient temperature: +10 ° C to +40 ° C (22±2 ° C recommended)
Ambient humidity: 60±5%RH
